  • Ragley Trig Hardtail Frame

    The Ragley Trig is a strong, stylish and versatile hardtail frame that is ideal for gravel racing, trail riding, inner-city errands and long-distance bikepacking adventures. It features a durable and lightweight Chromoly (CrMo) steel frame, carbon forks and is ideal for use with 700c or 27.5" tyres and offers a max tyre width of 45c/2.1".

    The Trig has been a firm favourite for a massively diverse group of riders. We have seen them fully loaded for multi-day adventures, shod with slicks as an urban commuter, or just ridden stock for local lockdown sanity missions.

    The Trig frameset features a 44mm headtube, multiple bottle cage mounts and tyre clearance to run any 700 or 650 gravel tyre option you want (and up 2.1” wide MTB tyres on 27.5” wheels). Want to get a little rowdier with your drop-bar endeavours? It’s even dropper post compatible for future off-road biased upgrades.

    The frame is engineered from custom triple-butted 4130 Chromoly steel tubing resulting in a frame that is lightweight and supple enough to provide comfort on longer trail rides whilst robust and stiff enough to take some serious abuse. The carbon fork features a 12mm thru-axle and the mounting points you need to take to the backcountry.

    We’re not going to pigeonhole the trig as gravel or adventure anymore. It’s all the same thing. We just made a super fun and reliable frame for you to go find your own adventure.


    • 5 Year Warranty and lifetime crash replacement
    • Material: 4130 Chromoly steel frame & Carbon fork
    • ISO 4210 Certified
    • Head Angle: 70˚Static
    • Effective Seat Angle: 74˚
    • Chainstay Length: 425mm
    • Seatpost: 27.2mm
    • Front Axle: Ragley 12mm x 100mm Thru-Axle
    • Rear Axle: Ragley 12mm x 142mm Thru-Axle
    • BB Shell: 68mm BSA
    • Headset: ZS44/28.6 | EX44/40
    • Wheel Size: 700c
    • Max Tyre Size: 700x45c/27.5×2.1"
    • BB Drop: -66mm
    • Rack & Fender mounts
    • Weight: Approximately 2.9kg / Frame 2.32kg / Fork 0.58kg

    Buy Ragley Frames & Forks from Chain Reaction Cycles, the World's Largest Online Bike Store.


    • Colour: Ultra Violet
    • Frame Size: XL, L, M
    • Gender: Unisex
    • Material: Steel
